Remote Commands
R&S
®
FSW
991User Manual 1173.9411.02 ─ 43
14.5.12.1 Determining the TOI
All remote control commands specific to TOI measurements are described here.
Useful commands for TOI measurements described elsewhere
CALCulate<n>:DELTamarker<m>:X on page 1154
CALCulate<n>:DELTamarker<m>:X:RELative? on page 1169
CALCulate<n>:DELTamarker<m>:Y on page 1169
CALCulate<n>:MARKer<m>:X on page 1156
CALCulate<n>:MARKer<m>:Y on page 1169
Remote commands exclusive to TOI measurements
CALCulate<n>:MARKer<m>:FUNCtion:TOI[:STATe].......................................................... 991
CALCulate<n>:MARKer<m>:FUNCtion:TOI:SEARchsignal ONCE...................................... 991
CALCulate<n>:MARKer<m>:FUNCtion:TOI:RESult?......................................................... 992
CALCulate<n>:MARKer<m>:FUNCtion:TOI[:STATe] <State>
This command initiates a measurement to determine the third intercept point.
A two-tone signal with equal carrier levels is expected at the RF input of the instru-
ment. Marker 1 and marker 2 (both normal markers) are set to the maximum of the two
signals. Delta marker 3 and delta marker 4 are positioned to the intermodulation prod-
ucts. The delta markers can be modified separately afterwards with the
CALCulate<n>:DELTamarker<m>:X command.
The third-order intercept is calculated from the level spacing between the normal mark-
ers and the delta markers.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
Example:
CALC:MARK:FUNC:TOI ON
Switches on the measurement of the third-order intercept.
CALCulate<n>:MARKer<m>:FUNCtion:TOI:SEARchsignal ONCE
This command initiates a search for signals in the current trace to determine the third
intercept point.
Suffix:
<n>
.
irrelevant
<m> irrelevant
Manual operation: See "Search Signals" on page 325
