Rohde & Schwarz CMW 500 - Configuring the List Mode; Performing a Single Shot Measurement

R&S
®
CMW 500 GPRF Applications
GPRF Programming
Operating Manual 1202.3986.32 – 03 169
CONFigure:GPRF:MEASurement:POWer:FILTer:GAUSs:BWIDth 30E+3
FPRINT ************************************************************
FPRINT Configure power measurement trigger
FPRINT ************************************************************
CONFigure:GPRF:MEASurement:POWer:TRIGger:SOURce IFPower
CONFigure:GPRF:MEASurement:POWer:TRIGger:SLOPe REDGe
CONFigure:GPRF:MEASurement:POWer:TRIGger:THReshold -25
CONFigure:GPRF:MEASurement:POWer:TRIGger:OFFSet 50E-6
CONFigure:GPRF:MEASurement:POWer:TRIGger:TOUT 2
CONFigure:GPRF:MEASurement:POWer:TRIGger:MODE ONCE
WAITKEY >Configuration completed, press "OK" to start
measurement<
7.3.2.4 Performing a Single Shot Measurement
FPRINT ************************************************************
FPRINT Start single-shot measurement, return RMS-averaged power in last measured
timeslot.
FPRINT Repeat measurement, return average power over the entire
FPRINT statistics cycle of 5 slots. Query the measurement state (should be "RDY").
FPRINT ************************************************************
READ:GPRF:MEASurement:POWer:RMS:CURRent?
READ:GPRF:MEASurement:POWer:RMS:AVERage?
FETCh:GPRF:MEASurement:POWer:STATe?
WAITKEY >Single-slot measurement completed, press "OK" to
configure list mode<
7.3.2.5 Configuring the List Mode
FPRINT ************************************************************
FPRINT Set up a measurement in list mode and over 8 slots (1 GSM frame).
FPRINT Query no.of measured slots (8), Query and modify the frequency and
expected
FPRINT nominal power of the first slot.
FPRINT ************************************************************
CONFigure:GPRF:MEASurement:POWer:LIST ON
CONFigure:GPRF:MEASurement:POWer:LIST:STARt 0
CONFigure:GPRF:MEASurement:POWer:LIST:STOP 7
CONFigure:GPRF:MEASurement:POWer:LIST:COUNt?
