R&S
®
CMW 500 WiMAX Applications
WiMAX Command Reference
Operating Manual 1202.3986.32 – 03 404
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
FETCh:WIMax:MEAS<i>:MEValuation:QERRor:CURRent?
FETCh:WIMax:MEAS<i>:MEValuation:QERRor:AVERage?
FETCh:WIMax:MEAS<i>:MEValuation:QERRor:MAXimum?
FETCh:WIMax:MEAS<i>:MEValuation:QERRor:MINimum?
READ:WIMax:MEAS<i>:MEValuation:QERRor:CURRent?
READ:WIMax:MEAS<i>:MEValuation:QERRor:AVERage?
READ:WIMax:MEAS<i>:MEValuation:QERRor:MAXimum?
READ:WIMax:MEAS<i>:MEValuation:QERRor:MINimum?
Returns the quadrature mismatch derived from the I/Q imbalance; see Table of
Results. The current, average, maximum and minimum values can be retrieved.
Returned values
<Reliability>, Reliability indicator
<Quad Mismatch> Range: –100.0 dB to 0.0 dB
Def. unit: dB
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
10.3.2.10 Measurement Results (Center Frequency Error, Burst Power, Crest
Factor, CINR)
The following commands return the frequency error, burst power, crest factor.
FETCh:WIMax:MEAS<i>:MEValuation:CFERror:CURRent?
FETCh:WIMax:MEAS<i>:MEValuation:CFERror:AVERage?
FETCh:WIMax:MEAS<i>:MEValuation:CFERror:MAXimum?
FETCh:WIMax:MEAS<i>:MEValuation:CFERror:MINimum?
READ:WIMax:MEAS<i>:MEValuation:CFERror:CURRent?
READ:WIMax:MEAS<i>:MEValuation:CFERror:AVERage?
READ:WIMax:MEAS<i>:MEValuation:CFERror:MAXimum?
READ:WIMax:MEAS<i>:MEValuation:CFERror:MINimum?
Returns the center frequency error; see Table of Results. The current, average,
maximum and minimum values can be retrieved.
