CMW 500 GSM Applications
GSM Command Reference
Operating Manual 1202.3986.32 – 03 282
CONFigure:GSM:MEAS<i>:MEValuation:LIMit:GMSK:SSWitching:MPOint<offsetn
o>
<Power Limit 1>, ..., <Power Limit 10>, <Status>
Defines and activates a limit line for the modulation scheme GMSK for a certain
frequency offset. The specified limits apply at the reference power values defined by
the previous command. Between the reference power values the limits are determined
by linear interpolation.
<offsetno>
Number of the frequency offset value. The offsets are defined by
the command
CONFigure:GSM:MEAS<i>:MEValuation:SSWitching:FO
FFsets
Range: 1 to 20
Def. value: 1
<Power Limit 1>,
...,
<Power Limit 10>,
Relative power limit applicable at the corresponding reference
power (see previous command).
Range: -60 dB to 30 dB
Def. values: see table below
Def. unit: dB
<Status> ON: Enable limits for the given <offsetno>
OFF: Disable limits for the given <offsetno>
Def. values: see table below
Characteristics Firmware version V1.00
Default values for <Status> (ON/OFF) and <Power Limit n> (values in dB) depending
on <offsetno>:
<Status> n=1 n=2 n=3 n=4 n=5 n=6 n=7 n=8 n=9 n=10
<offsetno>=1 ON -13 -15 -17 -19 -21 -23 -23 -23 -23 -23
<offsetno>=2 ON -21 -21 -21 -21 -23 -25 -26 -26 -26 -26
<offsetno>=3 ON -21 -21 -21 -21 -23 -25 -27 -29 -31 -32
<offsetno>=4 ON -24 -24 -24 -24 -26 -28 -30 -32 -34 -36
<offsetno>=5 to 7 OFF 0 0 0 0 0 0 0 0 0 0
<offsetno>=8 to 20 OFF 0 -15 -17 -19 -21 -23 -23 -23 -23 -23
CONFigure:GSM:MEAS<i>:MEValuation:LIMit:EPSK:SSWitching:PLEVel
<Status 1>, ..., <Status 10>, <Power Level 1>, ..., <Power Level 10>
Defines and activates reference power values for the modulation scheme 8PSK. These
values are relevant in the context of the next command.
