R&S
®
CMW 500 WCDMA Applications
WCDMA Command Reference
Operating Manual 1202.3986.32 – 03 332
Def. unit: dB
Example See Specifying General Measurement Settings
Characteristics Firmware version V1.00
CONFigure:WCDMa:MEAS<i>:RFSettings:FREQuency <Frequency>
Selects the center frequency of the RF analyzer.
<Frequency> Range: 100 MHz to 3300 MHz (increment 0.1 Hz)
Def. value 1922.600 MHz
Def. unit: Hz
Example See Specifying General Measurement Settings
Characteristics Firmware version V1.00
9.4.1.3 Signal Routing
The following commands select the connector and define an external attenuation
value.
ROUTe:WCDMa:MEAS<i>:RFSettings:CONNector <Input Connector>
Selects the input connector for the measured RF signal.
<Input Connector> RF1C: RF 1 COM
RF2C: RF 2 COM
Def. value: RF1C
Example See Specifying General Measurement Settings
Characteristics Firmware version V1.00
CONFigure:WCDMa:MEAS<i>:RFSettings:EATTenuation <External Att>
Defines an external attenuation (or gain, if the value is negative), to be applied to the
selected RF input connector (ROUTe:...:MEAS<i>:RFSettings:CONNector).
<External Att> Range: –50.00 dB to +90.00 dB (increment 0.01 dB)
Def. value: 0.00 dB
Def. unit: dB
Example See Specifying General Measurement Settings
Characteristics Firmware version V1.00
