SATO CL6NX Programming Reference

282
Aztec Code Table
SS II SS OO
bb88 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
bb77 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1
bb66 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1
bb55 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
BB44 bb33 bb22 bb11 00 11 22 33 44 55 66 77 88 99 AA BB CC DD EE FF
0 0 0 0 00 SP 0 @ P ｀ p
0 0 0 1 11 ! 1 A Q a q
0 0 1 0 22 ” 2 B R b r
0 0 1 1 33 # 3 C S c s
0 1 0 0 44 $ 4 D T d t
0 1 0 1 55 % 5 E U e u
0 1 1 0 66 & 6 F V f v
0 1 1 1 77 ’ 7 G W g w
1 0 0 0 88 ( 8 H X h x
1 0 0 1 99 ) 9 I Y i y
1 0 1 0 AA * : J Z j z
1 0 1 1 BB + ; K [ k {
1 1 0 0 CC , < L ＼ l
1 1 0 1 DD - = M ] m }
1 1 1 0 EE . > N ^ n ~
1 1 1 1 FF / ? O _ o
DEL
Data n Data n+1
FNC1 1BH 30H
ECI 1BH 31H to 36H
Aztec code is settable within the range (00H – FFH).
To set 1BH, specify [1BH,1BH]
To set FNC1, specify [1BH, 30H].
To set ECI, specify [1BH, *]. (‘*’ refer from 31H to 36H.)
Parent topic 2D Code

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
