SATO CL6NX Programming Reference

413
Gen 2 basic operation parameters (can be omitted)
usr: USER memory write Specify numbers to write to USER area in
hexadecimals.
It must be specified in digits that are multiples of 4.
The numbers should be within 4-128 digits, but the
maximum number of digits depends on the tag in use.
You may also use the space, tab, line feed in data
separator, but these codes will be skipped.
usa: USER memory
ASCII write
Specify numbers to write to USER area in ASCII.
Data that includes Control code (00H-1FH) can be
written as well.
Note that size information of the data area separated
with comma is required in front of the data.
Example:
If the data size is 64, specify usa:64,abcde...
The digits should be a multiple of 2.
The numbers should be specified within 2- 64 digits,
but the maximum number of digits depends on the
tag in use.
Operation parameters in standard format (can be omitted)
lck: Lock Specify the area to be locked by five bits in binary
code such as lck:10101.
The display order is USER, TID, ACCESS, KILL,
EPC, from the top. If the access password is
specified, it results in a password lock, and if the
access password is not specified, it results in a
permanent lock.
Note
• Impinj Monza R6 is an IC chip for which EPC
permanent lock is only an available feature. Using
11111 for 5-bit block (ex. “lck:11111”) can use the lock
feature.
lc2: Lock Specify the area to be locked by 10-digit character
(ex. lc2:1011XX0001) .
00:Unlock
01:Permanent Unlock
10:Password Lock/Password Read Lock
11: Permanent Lock
XX:Mask
From high - order bit: USER, TID, ACCESS, KILL,
EPC.
Note
• Impinj Monza R6 is an IC chip for which EPC
permanent lock is only an available feature. However
using 1111111111 for 10-bit block (ex. “lc2:1111111111”)
can use a lock feature.
apw: Access password To perform locking or read protecting with a
password, specify an eight-character HEX code.
psw: Unlocking password To access an area on which a password lock or
password read lock is applied, specify the same
number sequence as that used when locking. Specify
unlocking area with lck:.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
