SATO CL6NX Programming Reference

414
Operation parameters in standard format (can be omitted)
kpw: Kill code Specify the kill code with eight-character HEX code.
You cannot execute the kill by writing the code only.
NXP G2XL dedicated secure parameters (can be omitted)
(Cannot be used in a Gen2 chip other than NXP G2XL.)
rlk: G2X, Read protection Specify 0 or 1 to indicate whether read protection
is to be set or canceled. 1 for set and 0 for reset.
When read protection is set, the reading of all areas
becomes restricted.
You must concurrently use an access password
other than “00000000”, and for reset, specify the
same number sequence as the access password
used during setting, in the cancellation password
(dedicated for NXP G2XL).
eas: G2X, EAS bit data Specify 0 or 1 as the value of the EAS bit. 1 for set
and 0 for reset.
You must concurrently use an access password
other than “00000000”, and for reset, specify the
same number sequence as the access password
used during setting, in the cancellation password
(dedicated for NXP G2XL).
NXP G2iM/G2iL dedicated secure parameters (can be omitted)
(Cannot be used in a Gen2 chip other than NXP G2iM/G2iL.)
rlk: G2I, Read protection Specify 0 or 1 to indicate whether read protection
is to be set or canceled. 1 for set and 0 for reset.
When read protection is set, the reading of all areas
becomes restricted.
You must concurrently use an access password
other than “00000000”, and for reset, specify the
same number sequence as the access password
used during setting, in the cancellation password
(dedicated for NXP G2im/G2iL).
eas: G2I, EAS bit data Specify 0 or 1 as the value of the EAS bit. 1 for set
and 0 for reset.
You must concurrently use an access password
other than “00000000”, and for reset, specify the
same number sequence as the access password
used during setting, in the cancellation password
(dedicated for NXP G2im/G2iL).
Feed control parameters (can be omitted)
fsw: Feed without printing Usually, for RFID write item without print data, only
writing of RFID data is performed, and the label is not
fed. (Except for cases where the tag offset is set to
other than default.)
When “1” is specified in this parameter, the label is
fed even if the item does not contain print data.
When “0” is specified for this parameter, the label
is not fed for the item without print data, and the
operation is the same as when fsw: is not specified.
If labels are not fed, short buzzer will sound 2 times
when write is successful. Short buzzer will the sound
6 times when writing fails.
In addition, if 2 is specified for the item including
print data, a write test can be performed without

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
