415
Feed control parameters (can be omitted)
consuming a label as only write is executed without
feed/print.
Valid range: 0-2
SSCC96/SGTIN96 standard code conversion parameters
enc: Declaration of code standard
conversion
Declare when executing conversion according to
the code standard. SSCC96 and SGTIN96 can be
specified. If you specify ‘a’, it indicates SSCC96, and
if you specify ‘c’, it indicates SGTIN96.
The converted data is written in the EPC area.
Therefore, you can no longer use the epc: parameter
identifier
Valid range: a, c
flt: Filter value Specify the filter value with the number from 0 to 7.
Refer to the filter value standard table described later.
com: Company prefix Specify the company prefix with 6 to 12-digit decimal
number.
In the case of SSCC96, specify the serial reference
with 5 to 11-digit decimal number together with the
number sequence specified in com:, so that the value
is 17 digits or less. Even if the value does not reach
17 digits, leave it as is since the upper digits are filled
with a zero inside the printer.
srl: Serial reference
In the case of SGTIN96, specify the serial number
with 12-digit fixed decimal number. Specify
274877906943 or a smaller number.
It becomes a parameter error in the case of less than
12 digits.
itm: Item reference
(Only for SGTIN96)
Specify the item reference with 1 to 7-digit decimal
number together with the number sequence specified
in com:, so that the value is 13 digits or less. Even
if the value does not reach 13 digits, leave it as is
since the upper digits are filled with a zero inside the
printer.
Coding examples of the standard format (three-character parameter identifier)
[Coding example 1]
When data is written in an arbitrary length in the EPC region in the IC chip manufacturer extension
specifications tag
<A>
<V>50<H>50<XM>SECURE RFID EPC DATA WRITE
<IP0>e:h,epc:01234567890123456789012345678901;(in digits that are multiples of 4)
<Q>1
<Z>
[Coding example 2]
When EPC and user memory are written in a batch in the IC chip manufacturer extension
specifications tag, and permanent locking is performed
<A>
<V>50<H>50<XM>SECURE RFID EPC & USER DATA WRITE
<IP0>e:h,epc:01234567890123456789012345678901,usr:012345678.........5676789012345678901,lck:10001;
<Q>1
<Z>
