416
[Coding example 3]
When data is written in EPC by specifying the SSCC96 standard code conversion in the Gen2 tag,
and permanent locking is performed
<A>
<V>50<H>50<XM>SECURE RFID SSCC96 DATA WRITE
<IP0>e:h,enc:a,flt:0,com:12345678,srl:012345678,lck:00001;
<Q>1
<Z>
[Coding example 4]
When data is written in EPC by specifying the SGTIN96 standard code conversion in the Gen2 tag
<A>
<V>50<H>50<XM>SECURE RFID SGTIN96 DATA WRITE
<IP0>e:h,enc:c,flt:0,com:123456,itm:0123456,srl:012345678901;
<Q>1
<Z>
Conventional format
The format for Gen2 (Class1Generation2) tag only.
Use the standard format for the tag from the IC chip manufacturer having an EPC area of more than
96 bits.
<IP0>e: Write these parameters after specifying *.
Conventional format: One-character parameter identifier (SSCC96 code conversion / SGTIN96 code
conversion / free mapping)
EPC data parameter
Specify the EPC data. The restrictions on the number of digits based on
each EPC encoding type are as follows:
When SSCC96 code conversion is
specified
<IP0>e:a,..
A 17-digit decimal number
sequence in which the company
prefix and serial reference are
joined together
When SGTIN96 code conversion
is specified
<IP0>e:c,..
A 13-digit decimal number
sequence in which the company
prefix and item reference are
joined together
d: EPC data
When free mapping is specified
<IP0>e:z,..
A hexadecimal string containing
24 or less number of digits in
multiples of four, which is written
without conversion in the EPC
area. Use the standard format in
an application exceeding 24 digits
(96 bits).
You may also use the space, tab,
line feed in data separator, but
these codes will be skipped.
SSCC96/SGTIN96 conversion parameter
f: filter value Filter value
Refer to the filter value standard table described later.
c: company prefix Number of digits of the company prefix
