SATO CL6NX Programming Reference

417
SSCC96/SGTIN96 conversion parameter
A number from 6 to 12. Number of digits of the
company prefix in the first half of the data specified in
the d parameter.
s: serial reference Number of digits of Serial reference (only when
selecting SSCC96)
Number of digits of the serial reference in the latter
half of the data specified in the d parameter. Specify
a number from 5 to 11, so that when combined with c,
the resultant value is 17.
t: item reference Number of digits of Item reference (only when
selecting SGTIN96)
Specify a number from 1 to 7, so that when combined
with c, the resultant value is 13.
n: serial number Serial number 12 digits (fixed) (only when selecting
SGTIN96)
Specify 274877906943 or a smaller number.
Feed control parameters (can be omitted)
g: Feed without printing Usually, for RFID write item without print data, only
writing of RFID data is performed, and the label is not
fed. (Except for cases where the tag offset is set to
other than default)
When “1” is specified in this parameter, the label is
fed even if the item does not contain print data.
When “0” is specified for this parameter, the label
is not fed for the item without print data, and the
operation is the same as when g: is not specified.
Gen 2 memory bank operation parameters (can be omitted)
u: User Memory HEX Specify numeric string to write to USER area in
hexadecimals. Specified digits must be multiples of 4.
This can be specified in the range of 4 to 128 digits,
but the maximum number of digits depends on the
used tag.
You may also use the space, tab, line feed in data
separator, but these codes will be skipped.
v: User Memory ASCII Specify numeric string to write to USER area in ASCII
data. It is necessary to have data area and data size
information separated with a comma before the data.
For example in specifying a data size as 16, specify
as follows:
V:16,abcd…
Specified digits must be multiples of 2. This can
be specified in the range of 2 to 64 digits, but the
maximum number of digits depends on the used tag.
o: AFI code Application Family Identifier. Specify a hexadecimal
number from 0H to 1FFH. To write as AFI, specify the
ninth bit (MSB) as 1.
m: Locking 5-digit binary number. Set the bit of the bank to be
locked as 1.
If you specify the access code, it results in a
“password lock”, and if you omit the access code, it
results in a “permanent lock”.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
