SATO CL6NX Programming Reference

503
Record 13 bytes character of [4912345678904] from block 5 on the scratch pad, and lock the
specified block
(A format omitting b, RFID tag error ignore)
<A>
<V>50<H>50<BD>3020654912345678904
<RK>4,D13,4912345678904,wsb:5,lck:0010010010000000
<Q>1
<Z>
The scratch pad data after executing the example
Block
0
1
2
3
4
5
6
7
8
9...13
Data
4912345678904XXX
* The remaining byte XXX will be
filled with NULL.
Block to be locked
Use lck: to lock block
[Coding sample 4]
An example of rewriting only DFC (Data Format Code) to [FFE0H] without printing on the surface nor
changing the content of the scratch pad.
* In this case too, data is written to ID block.
<A>
<RK>4,D0,,df2:FFE0,fsw:1
<Q>10
<Z>
[Coding sample 5]
An example to record a URI "http://www.sato.com" of NFC(NDEF) format

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
