SATO CL6NX Programming Reference

509
Symbol Parameter name Valid range
Note: Specified in text format.
[Format of UID return data]
“Specify memory” + “:” + “Data” + “Line feed(0DH, 0AH)”
ee:f…f[CR][LF]
[IDm return data]
Symbol Parameter Valid range
e Specifies memory DM: IDm + PMm + ID block
f Data Maximum 64 digits
[IDm return format]
Returns a 64-digit hexadecimal numeric block as a result of IDm+PMm+ID block
IDm(16 digits)
PMm(16
digits
)
ID
block
(32
digits
)
03FEFFE0536C92A8
03014B024F4993FF
3031323334353637
FFE0123456789ABC
The above is just a sample.
Sample
data）
DM: 03FEFFE0536C92A803014B024F4993FF3031323334353637FFE0123456789ABC
[Return data format (when a command error occurs)]
[NAK]<15>
16
[Exception processing]
Exception conditionParameter name
A value outside the range is specified The specified size and
received size are different
Identifier Command error Invalid receive data
Terminology Description
Command error The data received after a command error is determined is not
considered as a parameter of this command.
Invalid receive data The data corresponding to Byte 2 and thereafter of the identifier is
ignored.
[Coding Sample]
<A>
<RU>,01
<RK>4,D13,4912345678904
<XM>4912345678904
<Z>
[Sample of status reply ]
When [DC2]PK is received using a tag with 03FEFFE0536C92A8 of IDm.
• Write successful (IDm read successful)

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
