567
[Format of TID/EPC return data]
“Specify
memory”＋“:”＋“Data” ＋“Line feed(0DH、0AH)”
ee:f…f(,gg:h…h) [CR][LF]
Specifying the memory to be record
Parameters of the IF:RFID settings section of the [DC2]PA-Printer settings
DATA_TO_RECODE: The data to be read differs according to the settings of the RFID data record.
"0": BOTH (EPC and TID are returned)
"1": EPC (only EPC is returned)
"2": TID (only TID is returned)
A setup example of [DC2]PA is shown below.
[DC2]PA,24,IF,18, DATA_TO_RECODE:0[CR][LF]
To set the above from settings menu, you can do the same from [Interface] > [RFID] > [Data to
Record].
[EPC/TID return data]
Symbol Parameter name Valid range
e(g...) Specify memory EP: EPC
ID: TID
f(h...) Data
* Text format
Maximum 256 digits
Data sample)
EP:E0123456789ABCDEF0123456,ID:E200680612345678
[Return data format (when a command error occurs)]
[NAK]<15>
16
[Exception processing]
Exception conditionParameter name
A value outside the
range is specified
The specified size and
received size are different
Identifier Command error Invalid receive data
Terminology Description
Command error The data received after a command error is determined is not considered as a
parameter of this command.
Invalid receive data The data corresponding to Byte 2 and thereafter of the identifier is ignored.
[Coding Sample]
<A>
<RU>01
<IP0>e:h,epc:E0123456789ABCDEF0123456;
<XM>E0123456789ABCDEF0123456
<Z>
