SATO CL6NX Programming Reference

587
[Sample of status reply 2] (format set to HEX)
When "4912345678904" is recorded on FeliCa Lite/FeliCa Lite-S block 8000H with IDm =
"03FEFFE0536C92A8", PMm = "03014B024F4993FF" and ID block = "3031323334353637
FFE0123456789ABC" (subtract block set to default)
Command [DC2]PJ,F1,HX
Status reply [STX]22,04,ud:13,34393132333435363738393034[ETX]
Command [DC2]PJ,F1,F2,HX
Status reply [STX]98,04,
ud:13,34393132333435363738393034,
DM:03FEFFE0536C92A8,PM:03014B024F4993FF,
ID:3031323334353637FFE0123456789ABC[ETX]
Note: All data are continuous in reality.
ID data
USER data
Inlet type (FeliCa Lite/FeliCa Lite-S)
USER data
Inlet type (FeliCa Lite/FeliCa Lite-S)
USER data
[Sample of status reply 3]
When "4912345678904" is recorded on FeliCa Lite/FeliCa Lite-S block 8000H with IDm =
"03FEFFE0536C92A8", PMm = "03014B024F4993FF" and ID block = "3031323334353637
FFE0123456789ABC" (subtract block set to default)
Command [DC2]PJ,F2,NO
Status reply [STX]78,04, Inlet type (FeliCa Lite/FeliCa Lite-S)
DM:03FEFFE0536C92A8,PM:03014B024F4993FF,
ID:3031323334353637FFE0123456789ABC[ETX]
Note:All data are continuous in reality.
ID data
[Sample of status reply 4] (format set to ASCII)
When there is not an RFID tag or when an RFID tag is bad.
Command [DC2]PJ,F1,AS
Status reply [ [STX]2,06[ETX]
Inlet type (RFID tag none/reading error)
Command [DC2]PJ,FA,AS
Status reply [ [STX]2,06[ETX]
Inlet type (RFID tag none/reading error)

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
