Section 07 ENGINE MANAGEMENT (DI)
Subsection 02 (COMPONENT INSPECTION AND ADJUSTMENT)
COMPONENT CONNECTOR
TERMINAL
NUMBER
WIRE COLOR VALUE
Manifold air
temperature sensor
(MATS)
AMP no. 4 16 and 19 WH/GY and BK/WH 2280 - 2740 ohms
Water temperature
sensor (WTS)
AMP no. 4 9 and 11
TA/OR and BK/OR
2280 - 2740 ohms
Terminal 3 and
terminal 1 of MAPS
PU/BL
Terminal 6 and
terminal 3 of MAPS
WH/BL
Manifold air pressure
sensor (MAPS)
AMP no. 3
Terminal 7 and
terminal 2 of MAPS
BK/WH
0 ohm (continuity)
Exhaust gas
temperature sensor
(EGTS)
AMP no. 4 10 and 12
TA/GY and BK/TA
2280 - 2740 ohms
Knock sensor (KS) AMP no. 4 2 and 17 BK/BL and YL/BL 5 M ohms
RAVE solenoid (RS) AMP no. 4 20 and 23 PU/GY and BK/GY 24 ohms
AMP no. 3 21 and 22 RE/GN and WH/GN
.45 - .55 ohms
primary winding
Ignition coil MAG
Coil terminal C
and coil post
6800 - 10 200 ohms
secondary winding
w/ohightension
leads
AMP no. 3 20 and 23 RE/BL and WH/BL
.45 - .55 ohms
primary winding
Ignition coil PTO
Coil terminal C
and coil post
6800 - 10 200 ohms
secondary winding
w/ohightension
leads
MAG
5700 ohms
lead alone
High tension leads
PTO
White tape
4300 ohms
lead alone
