Technology instructions

10.3 Motion control

S7-1200 Programmable controller

System Manual, V4.2, 09/2016, A5E02486680-AK

701

Sensor

Type

Default

Changeable

Comment

Sen-

sor.DataAdaptation

DINT 0 R (with restart) Adaptation acti-

vate:

• 0: NO

• 1: YES

StatusSensor

Type

Comment

StatusSensor.AdaptationState DINT Adaptation status:

• 0: NOT_ADAPTED: Cannot take

over data.

• 1: IN_ADAPTATION: Data adapta-

tion has just started.

• 2: ADAPTED: Data are adapted.

• 3: NOT_APPLICABLE: Adaptation

not selected or not available for this

drive.

• 4: ADAPTATION_ERROR: Error

during adaptation:

– Axis cannot be enabled.

– Motion control displays a con-

figuration error.

ErrorWord

Type

Comment

...

Bool

Bit 15: Adaptation Error

Bool

ErrorID:

...

Bool
