RM0440 Rev 4 1205/2126
RM0440 Advanced-control timers (TIM1/TIM8/TIM20)
1226
28.6.18 TIMx capture/compare register 3 (TIMx_CCR3)(x = 1, 8, 20)
Address offset: 0x03C
Reset value: 0x0000 0000
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:0 CCR2[19:0]: Capture/compare 2 value
If channel CC2 is configured as output: CCR2 is the value to be loaded in the actual
capture/compare 2 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR1 register
(bit OC2PE). Else the preload value is copied in the active capture/compare 2 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on tim_oc2 output.
Non-dithering mode (DITHEN = 0)
The register holds the compare value in CCR2[15:0]. The CCR2[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the integer part in CCR2[19:4]. The CCR2[3:0] bitfield contains the
dithered part.
If channel CC2 is configured as input: CCR2 is the counter value transferred by the last
input capture 2 event (tim_ic2). The TIMx_CCR2 register is read-only and cannot be
programmed.
Non-dithering mode (DITHEN = 0)
The register holds the capture value in CCR2[15:0]. The CCR2[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the capture in CCR2[19:4]. The CCR2[3:0] bits are reset.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. CCR3[19:16]
rw rw rw rw
1514131211109876543210
CCR3[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
