Advanced-control timers (TIM1/TIM8/TIM20) RM0440
1206/2126 RM0440 Rev 4
28.6.19 TIMx capture/compare register 4 (TIMx_CCR4)(x = 1, 8, 20)
Address offset: 0x040
Reset value: 0x0000 0000
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:0 CCR3[19:0]: Capture/compare value
If channel CC3 is configured as output: CCR3 is the value to be loaded in the actual
capture/compare 3 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register
(bit OC3PE). Else the preload value is copied in the active capture/compare 3 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on tim_oc3 output.
Non-dithering mode (DITHEN = 0)
The register holds the compare value in CCR3[15:0]. The CCR3[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the integer part in CCR3[19:4]. The CCR3[3:0] bitfield contains the
dithered part.
If channel CC3 is configured as input: CCR3 is the counter value transferred by the last
input capture 3 event (tim_ic3). The TIMx_CCR3 register is read-only and cannot be
programmed.
Non-dithering mode (DITHEN = 0)
The register holds the capture value in CCR3[15:0]. The CCR3[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the capture in CCR3[19:4]. The CCR3[3:0] bits are reset.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. CCR4[19:16]
rw rw rw rw
1514131211109876543210
CCR4[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
