RM0440 Rev 4 511/2126
RM0440 Filter math accelerator (FMAC)
513
18.4.7 FMAC write data register (FMAC_WDATA)
Address offset: 0x18
Reset value: 0x0000 0000
Bits 7:2 Reserved, must be kept at reset value.
Bit 1 X1FULL: X1 buffer full flag
The buffer is flagged as full if the number of available spaces is less than the FULL_WM
threshold. The number of available spaces is the difference between the write pointer and
the least recent sample currently in use.
0: X1 buffer not full. If the WIEN bit is set, the interrupt request is asserted until the flag is
set. If DMAWEN is set, DMA write channel requests are generated until the flag is set.
1: X1 buffer full.
This flag is set and cleared by hardware, or by a reset.
Note: after the last available space in the X1 buffer is filled there is a delay of 3 clock cycles
before the X1FULL flag goes high. To avoid any risk of overflow it is recommended to
insert a software delay after writing to the X1 buffer before reading the FMAC_SR.
Alternatively, a FULL_WM threshold of 2 can be used.
Bit 0 YEMPTY: Y buffer empty flag
The buffer is flagged as empty if the number of unread data is less than the EMPTY_WM
threshold. The number of unread data is the difference between the read pointer and the
current output destination address.
0: Y buffer not empty. If the RIEN bit is set, the interrupt request is asserted until the flag is
set. If DMAREN is set, DMA read channel requests are generated until the flag is set.
1: Y buffer empty.
This flag is set and cleared by hardware, or by a reset.
Note: after the last sample is read from the Y buffer there is a delay of 3 clock cycles before
the YEMPTY flag goes high. To avoid any risk of underflow it is recommended to insert
a software delay after reading from the Y buffer before reading the FMAC_SR.
Alternatively, an EMPTY_WM threshold of 2 can be used.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109 8 765432 1 0
WDATA[15:0]
wwwwwww w wwwwww w w
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 WDATA[15:0]: Write data
When a write access to this register occurs, the write data are transferred to the address
offset indicated by the write pointer. The pointer address is automatically incremented after
each write access.
