105 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
L
Max.
32.1
Module length
W
Max.
18.5
Module width
H
Max.
7.3
Module height
I
Min.
2.2
Lead length
m
Max.
0.5
Lead "flash"
d
Aver.
28.0
Distance between lead rows
p
Aver.
1.27
Pin pitch
Dimensions are for reference only. Tibbo assumes no responsibility for any errors in
this Manual, and does not make any commitment to update the information
contained herein.
Ordering Info and Specifications
The EM200 has two sub-models in circulation- the EM200-00 and EM200-01. The
EM200-01 is a RoHS-compliant version of the EM200-00. There are no other
differences between these two versions. Currently, only the EM200-01 is being
manufactured.
Specifications
Ethernet interface
100/10BaseT Ethernet, magnetics not built-in
Serial ports
1 port; UART, Wiegand
(1)
, and clock/data
(1)
modes
UART capabilities
Baudrates up to 115'200bps;
none/even/odd/mark/space parity and 7/8 bits/char.;
full-duplex UART mode with optional flow control
(1)
and half-duplex UART mode with automatic direction
control
(1)
; RX, TX, RTS
(1)
, CTS
(1)
, DTR
(1)
, and DSR
(1)
lines provided.
Number of I/O lines
9 (TX and RX lines of the serial port are not included
into this count)
Max. load current for each
I/O line
10mA
Flash memory
128KBytes, 64KB available for your Tibbo BASIC/C
application
EEPROM memory
2048 bytes, 2040 bytes available to store application
data
Supported network
protocols
(1)
UDP
(1)
, TCP
(1)
, ICMP (ping)
(1)
, and HTTP
(1)
. Other
protocols (such as DHCP) are implemented as Tibbo
BASIC/C functions.
Number of simultaneous
UDP or TCP (HTTP)
connections
(1)
16
(1)
Nominal power supply
voltage (VCC pin)
DC 5V, +/- 5%
Max. operating current
220mA
Device temperature during
operation
(2)
55 degrees C
Operating temperature
-10 to +70 degrees C
Operating relative humidity
10-90%
Mechanical dimensions
(excl. leads)
32.1x18.5x7.3mm
Pin diameter
0.4mm
