Tibbo EM1000 User Manual

186Boards
© Tibbo Technology Inc.
RELAY1 (output)
Relay 1 control
GPIO32
30
RELAY2 (output)
Relay 2 control
GPIO33
28
RELAY3 (output)
Relay 3 control
GPIO34
26
RELAY4 (output)
Relay 4 control
GPIO35
24
RELAY5 (output)
Relay 5 control
GPIO36
22
RELAY6 (output)
Relay 6 control
GPIO37
20
*GPIO line configured as input (default state)
RS232/485 Port
There is a simple serial port that supports both RS232 and RS485 modes. The port
operates through two signal terminals. In the RS232 mode, these are RX and TX, in
the RS485 mode -- RX/TX+ and RX/TX-. There is no provision for flow control (RTS
and CTS lines are not present), or RS422 interface.
The serial port can be used, for instance, to connect to another IB100x board. In
the RS232 mode, the serial port can also be used to update the firmware of the
EM1000 module located on the NB10x0 board.
Serial port lines
Serial port lines are on terminal block 1:
Terminal #
Function
9
Sensors 3 and 4, positive line (+)
8
Sensor 4, negative line (-)
7
Sensor 3, negative line (-)
6
Sensors 1 and 2, positive line (+)
5
Sensor 2, negative line (-)
4
Sensor 1, negative line (-)
3
Serial port: RX (RS232); TX/RX- (RS485)
2
Serial port: TX (RS232); TX/RX+ (RS485)
1
SYSTEM (COMMON) GROUND
Serial port control
Four lines of the EM1000 module (located on the NB10x0 board) control the serial
port.
Line
Function
Corresponding
EM1000 I/O
IC1000 cable
line
RX (input)
Receive line of the serial
port
GPIO8/RX0
17
TX (output)
Transmit line of the serial
port
GPIO9/TX0
19
MODE
(output)
Mode selection:
HIGH - RS485
LOW (or input*) - RS232
GPIO44
14
