318Tibbo Project System (TPS)
© Tibbo Technology Inc.
7.2.9.30
#19, C2: DB9M Connector
Function: DB9M connector
Form factor: C2
Special needs: ---
Power requirements: ---
See also: #18, #20, #21
Details
---
7.2.9.31
#20, C2: Nine Terminal Blocks
Function: Nine terminal blocks
Form factor: C2
Special needs: ---
