Tibbo EM1000 User Manual

504Sensors (Probes)
© Tibbo Technology Inc.
Dimensions are for reference only. Tibbo assumes no responsibility for any errors in
this Manual, and does not make any commitment to update the information
contained herein.
Ordering and Specifications
Cable Probes are supplied in two versions:
· CP#01, CP#02, CP#03, and CP#04 devices have no mounting ears;
· CP#01E, CP#02E, CP#03E, and CP#04E devices have mounting ears for M2
screws.
Mounting ears are detailed in Outline Dimensions.
Specifications
Power supply range
5VDC±10%
CP#01 and CP#01E
(ambient temperature
sensor)
- Based on the MCP9808 IC;
- Functionally compatible with Tibbit #29;
- Measurement range: -40 to +125°C*;
- Measurement resolution: 0.25°C;
- Measurement accuracy: ±1°C.
CP#02 and CP#02E
(ambient temperature and
humidity sensor)
- Based on the HIH6130 IC;
- Functionally compatible with Tibbit #30;
-Temperature measurement:
-Measurement range: -25 to +50°C;
-Measurement resolution: 0.5°C;
-Measurement accuracy: not specified.
-Humidity measurement:
-Measurement range: 10 to 90%RH;
-Measurement resolution: 0.1%RH;
-Measurement accuracy: ±5%RH;
-Temperature range for valid humidity
measurements: +5 to +50°C.
CP#03 and CP#03E
(ambient light sensor)
- Based on the BH1721FVC IC;
- Functionally compatible with Tibbit #28;
- Measurement range: 1 to 65528 lux;
- Measurement resolution: 1 lux;
- Measurement accuracy: 1 lux.
CP#04 and CP#04E
(IR receiver/transmitter)
- Based on TSMP6000 infrared photo detector and
TSAL6100 infrared emitter;
- Functionally compatible with Tibbit #27.
Operating temperature
range
-40 to +85 degrees C
Operating relative
humidity
10-90%
Mechanical dimensions
- Without mounting ears: 22.0 x 29.0 x 12 mm
- With mounting ears: 33.0 x 29.0 x 12 mm
