345 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
Details
This C1 device requires the Tibbit #00-3 to be installed in the neighboring "M" Tibbit
socket.
The LED is to be controlled through line A of Tibbit #00-3. Set the line LOW to turn
the LED ON.
IMPORTANT NOTE! Red and blue LEDs used in this Tibbit are high-brightness LEDs
that are fairly visible in regular office lighting conditions. Green and yellow LEDs are
less bright and are only recommended for use in dimly lit environments (equipment
closets, etc.).
7.2.9.47
#40-1~4, M1S: Digital Potentiometer (Four Nominals)
Function: Digital potentiometer (5KOhm, 10KOhm, 50KOhm, and 100KOhm versions
available)
Form factor: M1S
Category: Input/output module
Special needs: ---
Power requirements: 5V/10mA
Mates with: #19, #20, #21 (limited use)
See also: ---
