LEDs
There is one red and one yellow LED. The red LED is connected to the SCL line of
the I2C interface; the yellow LED – to the SDA line.
Sample project
The use of this Tibbit is illustrated by a Tibbo BASIC test project. You can find it
here: https://github.com/tibbotech/CA-Test-Tibbit-53.
7.2.9.60
#54, M1S: Four Dry Contact Inputs
Function: Four dry contact inputs; external switches should be installed between
the input terminals and the system ground.
Form factor: M1S
Category: Input module
Special needs: ---
Power requirements: 5V/40mA
Mates with: #19, #20, #21 (limited use)
See also: #04-1, #04-2, #04-3, #04-4, #04-05, #04-06, #04-07, #04-08
