Tibbo EM1000 User Manual

378Tibbo Project System (TPS)
© Tibbo Technology Inc.
Blue level, LED 1
---
White level, LED 1
---
* LED numbers (N, 2, 1) correspond to numbers on the diagram above.
Data format for SPI read transactions
No read transactions are supported in this configuration.
Sample project
The use of this and other "I2C/SPI" Tibbits is illustrated by a group of Tibbo BASIC
test projects. You can find them at
http://tibbo.com/basic/resources/i2c_tibbits.html. The smart LED project is titled
test_tibbit_57_sled.
7.2.9.63
#58, M1S: Two 24V NPN Isolated Open Collector Outputs
Function: Two 24V NPN isolated open collector outputs
Form factor: M1S
Category: Output module
Special needs: ---
Power requirements: 5V/20mA (with both transistors activated)
Mates with: #19, #20, #21
See also: #03-1, #03-2, #06, #07, #15, #59
