Ordering Info and Specifications
The DS1202 device is only available in a single configuration and can be order as
"DS1202".
Hardware specifications
Ethernet interface
10/100BaseT Ethernet, Auto-MDIX
Serial ports
One RS232 port (DB9M) with 3.5 serial channels
(four inputs and three outputs)
UART capabilities
Baudrates up to 921'600bps;
none/even/odd/mark/space parity and 7/8
bits/character.
Clock frequency
11.0592MHz with PLL off
88.4736MHz with PLL on
Flash memory
1024KBytes, entire memory minus 64KB is available
to store Tibbo BASIC/C application and data.
Typical write endurance is 100'000 write cycles per
256-byte sector. See the warning in Flash and
EEPROM Memory.
EEPROM memory
2048 bytes, 2020 bytes available to store
application data.
Typical write endurance is around 1'000'000 write
cycles per 16-byte EEPROM sector. See Prolonging
and Estimating EEPROM life.
Supply voltage range
DC 10-24V (12V nominal)
Operating temperature
-5 to +70 degrees C
Operating relative humidity
10-90%
Mechanical dimensions
60x47x30mm
Carton dimensions
125x95x52mm
Gross weight
110g
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
