Tibbo EM1000 User Manual

177 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
#2, red
GPIO30
34
#1, green
GPIO31
32
*GPIO line configured as input (default state)
Ordering Info and Specifications
Use the following model numbers to order the IB1004 and SB1004 boards. Normally,
you will want to order both boards "in parallel":
IB1004
The IB1004 board and LB1001 LED board mounted
on the IB1004 and connected to the latter with the
LC1000 cable. Also included is the TB1004 test
board.
SB1004
The SB1004 supplementary board. Order this board
"in parallel" with the IB1004.
Note: the IB1004 and SB1004 plug into each other. No soldering is required to
interconnect them.
Hardware specifications
A/D channels
8 channels, 24-bit resolution
D/A channels
4 channels, voltage and current output, 14-bit
resolution
Relays
2 relays, 24V/1A
Serial port lines
RS232 mode: RX, TX
RS485 mode: RX+/-, TX+/-
Baudrate
Up to 460800bps
Operating temperature
-30 to +80 degrees C
Operating relative humidity
10-90%
Dimensions
76x85mm
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
5.3.2.3
IB1005 and SB1005 (Digital I/O)
Featuring 8 opto-isolated inputs and 6 relay outputs, the IB1005 + SB1005 board
combination is perfect for automation, security, access control, and monitoring
applications. An additional RS232/485 port further expands product capabilities.
