247 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
·
One WAS-P0005(B) serial cable. Can be used for firmware upgrades through the
serial port.
Additionally, any board or accessory from the EM1000-TEV system can be
purchased separately.
EM500EV/EM510EV
The EM500EV (with IB0 interface board)
The EM500EV and EM510EV Evaluation Systems offers a convenient way of testing
the EM500 and EM510 BASIC/C-programmable Embedded modules. The systems
consist of two boards:
·
EM500EV-MB0 motherboard with EM500 or EM510 module.
·
Either the "IB0" or "IB1" interface board:
- The EM500EV-IB0 board implements the RS232 interface with RX, TX, CTS, RTS,
DSR, and DTR lines.
