Tibbo EM1000 User Manual

190Boards
© Tibbo Technology Inc.
#4
Red
0
(1)
Controlled by the GPIO28 of the EM1000 (pin 38
on the interboard connector header).
#3
Green
0
(1)
Controlled by the GPIO29 of the EM1000 (pin 36
on the interboard connector header).
#9
---
---
<not installed>
#2
Red
0
(1)
Controlled by the GPIO30 of the EM1000 (pin 34
on the interboard connector header).
#1
Green
0
(1)
Controlled by the GPIO31 of the EM1000 (pin 32
on the interboard connector header).
Note 1. This resistor's value is 0 because there is another resistor connected in
series with the EM1000's GPIO line and located on the NB10x0 board.
Cable data
The following standard cables are supplied:
· IC1000 interboard cable
· LC1000 LED board cable
5.3.4.1
IC1000 Interboard Cable
NB10x0 and IB100x boards are interconnected by a 50-wire cable called the
"interboard cable". This cable can be ordered as IC1000. There is a 50-pin header on
each board to receive the cable end. The header type is 2x25, pitch=2.54mm.
Connector pin assignment is shown below. The IC1000 length is approximately 40mm
(as measured between the connectors). This cable is supplied with each NB10x0
board (but not with IB100x boards).
