Tibbo EM1000 User Manual

468External Controllers
© Tibbo Technology Inc.
The connector is of RJ45 type, pin assignment is as follows:
#1
TX+
#2
TX-
#3
RX+
#4
<No connection>
#5
<No connection>
#6
RX-
#7
<No connection>
#8
<No connection>
The Ethernet port of the DS1206 incorporates two Ethernet status LEDs.
8.2.1.3
Multi-channel RS232 Port
The DS1206 features a multi-channel RS232 port. Internally, the DS1206 has four
independent serial ports, and each of those ports can potentially have its own RX,
TX, CTS, RTS, DSR, and DTR lines. Physically, the RS232 port of the DS1206 has
three output lines and four input lines. Flexible mapping allows you to choose how
these inputs and outputs will be used.
The serial-over-IP application supplied with the DS1206 defines 15 mapping options.
These are presented in the table below:
Mappi
ng
optio
n
Available signals
Pins on the DB9M connector
Miss
ing
line
#
2
#3
#8
#7
#6
#4
#1
Optio
n 0
RX/TX/CTS/RTS/DS
R/DTR
RX
TX
CT
S
RT
S
DS
R
DT
R
---
---
Optio
n 1
RX/TX/CTS/RTS/DS
R/DTR + RX/tx
RX
TX
CT
S
RT
S
DS
R
DT
R
RX
4
tx4
Optio
n 2
RX/TX/CTS/RTS +
RX/TX + RX/tx
RX
TX
CT
S
RT
S
RX3
TX
3
RX
4
tx4
Optio
n 3
RX/TX/CTS/RTS +
RX/TX/CTS/rts
RX
TX
CT
S
RT
S
RX3
TX
3
CT
S3
rts3
Optio
n 4
RX/TX/CTS/RTS +
RX/TX/DSR/dtr
RX
TX
CT
S
RT
S
RX3
TX
3
DS
R3
dtr3
Optio
n 5
RX/TX/DSR/DTR +
RX/TX + RX/tx
RX
TX
RX2
TX
2
DS
R
DT
R
RX
4
tx4
