448External Controllers
© Tibbo Technology Inc.
DS110x Connectors and Controls
·
Power arrangement
·
Ethernet port
·
Serial port
·
Flash and EEPROM Memory
·
Buzzer (DS1101 and DS1102 only)
·
Optional Wi-Fi (DS1101 and DS1102 only)
·
Optional OLED display (DS1101 and DS1102 only)
·
LED bar (DS1101 and DS1102 only)
·
DIN rail and wall mounting plates
·
Status LEDs (main status LEDs and Ethernet link status LED)
·
Setup button
8.1.1.1
Power Arrangement
All DS110x devices are "normally" powered through the power jack.
The power jack accepts "small" power connectors with 3.5mm diameter. Use APR-
P0011, APR-P0012, or APR-P0013 power adaptor supplied by Tibbo or similar adaptor
with 12VDC nominal output voltage. Adaptor current rating should be at least
500mA. On the power jack, the ground is "on the outside", as shown on the figure
below.
