124Boards
© Tibbo Technology Inc.
you to generate external resets. The RST line has active LOW polarity. If you are
not using the RST line you can leave it unconnected.
PLL control
The EM2001 can run at three clock frequencies (speeds):
·
Full speed: 120MHz (default post-reset speed)
·
Medium speed: 43Mhz
·
Low speed: 16MHz
The clock speed can be changed programmatically, via the system (sys.) object.
For more information see TIDE, TiOS, Tibbo BASIC, and Tibbo C Manual.
Mode selection
The function of the MD line is described in Setup Button (MD line).
Mechanical Dimensions
