30Embedded Modules
© Tibbo Technology Inc.
- ppp — accesses the Internet over a serial modem (GPRS, etc.).
- pppoe — accesses the Internet over an ADSL modem.
- romfile — facilitates access to resource files (fixed data).
- rtc — keeps track of date and time.
- ser — controls serial ports (UART, Wiegand, clock/data modes).
- sock — socket comms (up to 16 UDP, TCP, and HTTP sessions).
- ssi — controls serial synchronous interface channels (SPI, I2C...).
- stor — provides access to the EEPROM.
- sys — in charge of general device functionality.
- wln — handles the Wi-Fi interface.
·
Variable Types: Byte, char, integer (word), short, dword, long, real, string, plus
user-defined arrays and structures.
·
Function Groups: 27 string functions, 8 date/time conversion functions,
encryption/hash calculation functions (RC4, MD5, SHA-1), and more.
EM1000-00 and -01
Small hardware changes were made to the EM1000 since its first release. Currently
Tibbo supplies version "-01" of the module. The first version ever produced was "-
00". The main difference is in the Ethernet IC: the EM1000-...-00 used Davicom's
DM9000 while the EM1000-...- 01 features newer DM9000A. This change reduced
module's current consumption and operating temperature. Unfortunately, this
transition requires certain alterations to the way Ethernet magnetics and RJ45 are
wired to the module. Tibbo apologizes for any inconvenience caused!
Throughout this document, differences between hardware versions of the module
are highlighted in pink. Please, note that from the programming standpoint there are
no functional differences between the EM1000-...- 00 and EM1000-...- 00.
Pictures below show the original EM1000-...- 00 and the EM1000-...- 01.
This is how the original EM1000-...- 00 looks like:
And this is how the EM1000-...- 01 looks like:
