Hardware specifications
Opto-isolated inputs
8 channels:
- channels 1-4: 2V-15V input range, can be used
to connect card readers
- channels 5-8: 5-50V input range
Relays
6 relays, 30VDC/16A or 250VAC/15A
Serial port lines
RS232 mode: RX, TX
RS485 mode: RX+/-, TX+/-
Baudrate
Up to 460800bps
Operating temperature
-30 to +80 degrees C
Operating relative humidity
10-90%
Dimensions
76x85mm
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
LB100x LED Boards
The following LED boards are currently supplied as standard.
· LB1000 (for NB10x0 network boards).
· LB1001 (for IB100x interface boards).
5.3.3.1
LB1000
The LB1000 is a standard LED board supplied with NB10x0 network boards. Table
below shows LED arrangement for this board. LED numbers correspond to the
numbers shown on the mechanical drawing for the LB1000. LED control is described
in the External LED Control topic of the NB1000 documentation.
LED
#
Color
Series
Resistor
value
(Ohm)
Function
#8
Green
0
(1)
Status LED, connected to the SG line of the
EM1000
(3)
#7
Red
0
(1)
Status LED, connected to the SR line of the
EM1000
(3)
#11
---
---
<not installed>
#6
Green
220
Ethernet status LED, connected to the EG line of
the EM1000
