Tibbo EM1000 User Manual

125 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
Dimensions are for reference only. Tibbo assumes no responsibility for any errors in
this Manual, and does not make any commitment to update the information
contained herein.
Ordering Info and Specifications
To order, use the "EM2001" ordering code.
Hardware specifications
Ethernet interface
10/100BaseT Ethernet, Auto-MDIX, with
RJ45/magnetics
Serial ports
4 ports, CMOS-level
UART capabilities
Baudrates up to 460'800bps;
none/even/odd/mark/space parity and 7/8
bits/character (7 bits/character and "none"
parity cannot be used together)
Number of I/O lines
56 lines (including 5 on the wireless add-on
connector);
all lines are 5V-tolerant;
40 of I/O lines are combined into five 8-bit
ports;
8 lines can be used as interrupt lines.
Max. load current for each
I/O line
10mA
Square wave generator
458Hz - 15MHz (with the full-speed clock),
primarily intended for driving an external buzzer
Real-time counter (RTC)
YES
RTC backup power source
Onboard coin cell
Clock frequency
120MHz at full speed
34MHz at medium speed
16MHz at low speed
Program flash memory
1MB program flash for TiOS and compiled
application binary. TiOS occupies 256KB. The
remaining 768KB can be used to store the
compiled application binary and permanent
(unchangeable) data.
Flash disk
1MB for hardened, fault-tolerant file system. The
entire disk can be used by the application to
store its data .
Typical write endurance is 100'000 write cycles
per 256-byte sector. See the warning in Flash
and EEPROM Memory.
EEPROM memory
2048 bytes, 2020 bytes available for storing
application's data.
Typical write endurance is around 1'000'000
write cycles per 16-byte EEPROM sector. See
Prolonging and Estimating EEPROM life.
