Tibbo EM1000 User Manual

239 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
io.num=PL_IO_NUM_47 'backlight
io.enabled=YES
io.state=LOW
6.3.3.2
TEV-LB1
The TEV-LB1 board carries a 128x96, 4-bit RITDISPLAY RGS13128096 OLED panel.
This panel is based on a SOLOMON SSD1329 controller.
Related datasheets, as well as the schematic diagram for the TEV-LB1 board can be
found on Tibbo website.
Interconnection between the EM1000 and the panel
Pin #
(1)
EM1000 I/O line
Panel
5
GPIO48
---
6
GPIO47
---
7
GPIO46
---
8
GPIO39/P4.7
D7
9
GPIO38/P4.6
D6
10
GPIO37/P4.5
D5
11
GPIO36/P4.4
D4
12
GPIO35/P4.3
D3
13
GPIO34/P4.2
D2
14
GPIO33/P4.1
D1
15
GPIO32/P4.0
D0
16
GPIO44
RST
17
GPIO43
D/C
18
GPIO42
R/W
19
GPIO41
E
20
GPIO40
CS
(1)
Pin number on the TEV-LB1 connector.
Required initialization code in Tibbo BASIC/C application
This section assumes that you are familiar with Tibbo BASIC/C and TIDE software.
These are documented in the TIDE, TiOS, Tibbo BASIC, and Tibbo C Manual.

Tibbo EM1000 Specifications

General

Brand	Tibbo
Model	EM1000
Category	Control Unit
Language	English
