Tibbo EM1000 User Manual

192Boards
© Tibbo Technology Inc.
2
VCC
3.3V power from the
"NB" ("IB").
3
LED8
Cathode (-) of LED #8.
4
LED7
Cathode (-) of LED #7.
5
LED11
Cathode (-) of LED #11.
6
LED6
Cathode (-) of LED #6.
7
LED5
Cathode (-) of LED #5.
8
LED10
Cathode (-) of LED #10.
9
LED4
Cathode (-) of LED #4.
10
LED3
Cathode (-) of LED #3.
11
LED9
Cathode (-) of LED #9.
12
LED2
Cathode (-) of LED #2.
13
LED1
Cathode (-) of LED #1.
14
GND
System ground.
Important note: For correct operation, a current-limiting resistor must be connected
in series with each LED. Most I/O lines of the EM1000 (installed on the NB1000
network board) already have a current-limiting resistor, so the resistor onboard the
IB100x is not always necessary. In this case, the 0 Ohm resistor is used.
Documentation for specific LB100x boards provides necessary info.
Mechanical data
The following drawings are provided in this section:
· NB10x0 and IB100x board dimensions
· SB100x board dimensions
· LB100x board dimensions
5.3.5.1
NB10x0 and IB100x Board Dimensions
The NB10x0 and IB100x have the same outline dimensions. Both types of boards also
feature identical 50-pin headers for the IC1000 interboard cable, as well as
mounting holes for the LB1000 LED board. The only difference is that on the "IB"
boards the 50-pin header is on the right, while the LB1000 mounting holes are on
the left. On the "NB" boards, the pin header is on the left, while the mounting holes
are located on the right.
