282Tibbo Project System (TPS)
© Tibbo Technology Inc.
#51, M1S: CAN bus [CAN] [DEPRICATED]
#52, M2T: Four-channel isolated +/-10V ADC
#53, M2T: Isolated 4-20mA ADC
#54, M1S: Four dry contact inputs
#56, C1: Type A USB port [USB] [DEPRICATED]
#57, M1S: FPGA Tibbit
#58, M1S: Two 24V NPN isolated open collector outputs
#59, M1S: Two 24V PNP isolated open collector outputs
7.2.9.1
#00-1, M1S: Four Direct I/O Lines
Function: Four directly exposed I/O lines of the microcontroller
Form factor: M1S
Category: Blank module
Special needs: ---
Power requirements: 5V/20mA
Mates with: #19, #20, #21 (limited use)
See also: #00-2, #00-3
Details
Sometimes you just want to work with CPU I/O lines directly -- no logic or circuitry
in between. This Tibbit is (basically) four wires that connect its control lines to I/O
