430Tibbo Project System (TPS)
© Tibbo Technology Inc.
PCB screw (all TPB models)
The LTPB3 can be purchased with an optional DIN rail mounting kit and an available
vibration protection kit (VPK), with which TPS devices meet the shock and vibration
resistance requirements of the IEC 60068-2-27 standard.
Size 3 Vibration Protection Kit (VPK) for LTPB3
The vibration protection kit (VPK) for the Size 3 Linux Tibbo Project Box consists of
a vibration protection plate and four special screws.
The plate is installed as shown on the exploded view of the TPS:
1. Four M2.5 screws securing the TPP are removed and the four special screws
(shown above) are instead used to attach the TPP onto the bottom cover.
2. The vibration protection plate goes over Tibbits (installed on the TPP) and rests
on the special screws.
3. Four M2.5 screws that originally held the TPP in place are used to secure the
vibration protection plate onto the special screws.
