301 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
Combine this Tibbit with terminal block devices -- #20 (nine terminal blocks) or #21
(four terminal blocks).
The original version of this Tibbit made no use of IO3 and IO4. Revision B of the
device now provide 5V power on IO3 and GND on IO4.
LEDs
There are three LEDs: two red and one green. Red LEDs are connected to TX and
OUT/-IN lines. The green LED is for the RX input. All LEDs are buffered (with logic
gates) and light up for the LOW state of control lines. Revision B devices are marked
by a small round sticker with letter "B". The sticker is on the side of the Tibbit.
7.2.9.17
#06, M2T: Two High-power Relays
Function: Two mechanical high-power relays with normally opened and normally
closed terminals
Form factor: M2T
Category: Output module
Special needs: ---
Power requirements: 5V/140mA (with both relays activated)
Mates with: #19, #20, #21
See also: #03-1, #03-2, #07, #15, #58, #59
