Tibbo EM1000 User Manual

355 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
#6
Isolated DTR
(output)
Isolated TX- (output)
Isolated TX- (output)
#7
Isolated DSR (input)
Isolated RX+ (input)
Isolated RX+ (input)
#8
<No connection>
Isolated RTS-
(output)
<No connection>
#9
<No connection>
Isolated CTS- (input)
<No connection>
LEDs
There are eight LEDs: five red and three green. Red LEDs are connected to TX, RTS,
DTR, FD/-HD, and -232/422-485 lines. Green LEDs are for RX, CTS, and DSR.
All LEDs are buffered (with logic gates) and light up for the LOW state of
corresponding control lines.
7.2.9.52
#45-1~3, H2: LTE (4G) Modem
Function: LTE (4G) modem
Form factor: H2
Category: Input/output module
Special needs: ---
Power requirements: 5V/500mA average, peak current consumption reaches 2A
Mates with: ---
See also: #47
