"C" socket (S29) exists exclusively for the installation of the RF connector Tibbit
#37. This socket has no other functions.
The jumpers
Four jumpers next to the RJ45 jack define the connection between the "M" socket
(S27), "C" socket (S28), and the RJ45 jack:
·
When the jumpers are in the 1-2 position, four power lines from the RJ45 jack are
connected to four I/O lines of (S27). Under this arrangement you can install an M1
PoE device into the (S27), or M2 PoE device into the (S25)-(S27).
·
When the jumpers are in the 2-3 position, the RJ45 jack is disconnected from the
socket (S27). The socket (S27) is instead connected to (S28) in a "standard tile
way".
7.3.1.3
Size 2 Tibbo Project PCB (TPP2)
Introduction
Size 2 Tibbo Project PCB (TPP2) runs Tibbo OS and is programmable in Tibbo BASIC
and Tibbo C.
TPP2 is perfect for systems with a medium number of I/O lines. The board can
optionally control a TFT display and a keypad, so it is suitable for applications
requiring a human-machine interface (HMI).
This product can be used as a bare board or assembled into a size 2 Tibbo Project
Box. For HMI applications, the board can also be assembled into the TPB2L box,
which features a 320x240 TFT LCD and a 4-button sensor keypad.
Featuring 3 tiles for a total of 6 "M" and 6 "C" sockets, the TPP2 can implement
configurations with up to four simple serial ports, up to 12 relays, or up to 24 opto-
inputs, PWM, or open-collector outputs.
