392Tibbo Project System (TPS)
© Tibbo Technology Inc.
The TPP2 is perfect for data collection and AutoID projects, as well as factory,
shop, data center, hotel, and home automation applications. The board contains
enough "C" sockets to simultaneously accommodate temperature, humidity,
pressure, ambient light, and shock sensors. With the use of appropriate Tibbits the
board can even control legacy IR devices by emulating traditional IR remote
controls.
Hardware features
·
Powered by Tibbo OS (TiOS)
·
10/100BaseT auto-MDIX Ethernet port (automatic detection of "straight" and
"cross" cables)
·
Optional Wi-Fi interface (requires the WA2000 add-on module)
·
Optional GPRS interface (requires Tibbit #47)
·
Three tiles with 24 general-purpose I/O lines
o Six sockets for Tibbit modules
o Six sockets for Tibbit connectors
o One extra socket for Tibbit #37
o Four Tibbit module sockets have UART capability
§
Baudrates of up to 921,600bps
§
None/even/odd/mark/space parity modes
§
7/8 bits/character
§
Full-duplex mode with RTS/CTS and XON/XOFF flow control
§
Half-duplex mode with direction control
§
Encoding and decoding of Wiegand and clock/data streams
o Each module socket has an interrupt capability
o One module socket has PoE capability
o Four remappable synchronous serial ports with SPI and I2C modes
·
Onboard buzzer
·
Connectors for the TFT LCD and sensor keypad of the TPB2L
·
RTC with a backup supercapacitor
·
22KB SRAM for Tibbo BASIC/C variables and data
·
1MB flash memory for TiOS, application code, and file system
·
2048-byte EEPROM for data storage
·
Eight onboard LEDs
o Green and Red main status LEDs
o Yellow Ethernet link LED
o Five blue LEDs (for Wi-Fi signal strength indication, etc.)
·
Software-controlled PLL for selecting high or low speed
·
Reliable power-on/ brown-out reset circuit
·
Power: 220mA @ 3.3V (100Base-T mode, full speed)
·
Dimensions (LxW): 94 x 94mm
·
Operating temperature range: -40°C to 70°C
·
Firmware is upgradeable through the serial port or network
