Tibbo EM1000 User Manual

164Boards
© Tibbo Technology Inc.
5
A/D channel 6, negative input (-)
4
A/D channel 6, positive input (+)
3
A/D channel 5, negative input (-)
2
A/D channel 5, positive input (+)
1
A/D GROUND (isolated from the rest of the device)
Terminal block 3
Terminal #
Function
9
D/A channel 4, current output
8
D/A channel 4, voltage output
7
D/A channel 3, current output
6
D/A channel 3, voltage output
5
D/A channel 2, current output
4
D/A channel 2, voltage output
3
D/A channel 1, current output
2
D/A channel 1, voltage output
1
D/A GROUND (isolated from the rest of the device)
Terminal block 4
Terminal #
Function
9
Relay 2, normally opened line
8
Relay 2, normally closed line
7
Relay 2, common line
6
Relay 1, normally opened line
5
Relay 1, normally closed line
4
Relay 1, common line
3
Serial port: TX (RS232); TX/RX+ (RS485)
2
Serial port: RX (RS232); TX/RX- (RS485)
1
SYSTEM (COMMON) GROUND
Control Lines
The following lines of the EM1000 module (located on the NB10x0 network board)
are used to control the IB1004 + SB1004.
In the tables below, "output" means an output of the EM1000, and "input" means an
input of the EM1000.
A/D converter control
For more information see A/D Converter.
Line
Function
Corresponding
EM1000 I/O
IC1000
cable line
