196Boards
© Tibbo Technology Inc.
* This is the standard gap; it will "happen" automatically when the boards are used
inside the DS10xx housing.
Dimensions are for reference only. Tibbo assumes no responsibility for any errors in
this Manual, and does not make any commitment to update the information
contained herein.
5.3.5.3
LB100x Board Dimensions
The LB100x LED board accommodates up to 11 LEDs. What LEDs are actually
installed depends on the board version. See LB100x LED Boards for description of
standard boards offered by Tibbo. The LB100x connects either to an NB10x0 board
or IB100x board. The LC1000 flat cable is used for this.
The LB100x can be mounted independently or attached to the "NB" ("IB") board. A
custom-made "brass offset" part BP1000 is used for the purpose in the latter case.
The BP1000 ensures precise 3.5mm gap between the LB100x and the "NB" ("IB")
board.
