The cable is of green color, approximately 1.5m long.
WAS-1499 'Straight' Ethernet Cable
WAS-1499 can be used to connect Tibbo Device Server or Evaluation Board to an
Ethernet hub.
Side A
Side B
#1 (pair 1)
#1
#2 (pair 1)
#2
#3 (pair 2)
#3
#6 (pair 2)
#6
The cable is of blue color, approximately 1.5m long.
WAS-1498 'Crossover' Ethernet Cable
WAS-1498 can be used to connect Tibbo Device Server or Evaluation Board directly
to some other Ethernet device (i.e. Ethernet port of the PC). This is a so called
"crossover" cable that can interconnect two Ethernet devices without a hub.
Side A
Side B
#1 (pair 1)
#3
#2 (pair 1)
#6
#3 (pair 2)
#1
#6 (pair 2)
#2
The cable is of green color, approximately 1.5m long.
12VDC Power Adaptors
The following adaptor models are now offered:
Products
Specifications
US
Europe
UK
EM120/200-EV
12VDC/0.5A,
non-switching,
"large" connector
(5.5mm)
APR-
1014
APR-
1015A
APR-
1018A
EM1000-EV
EM1000-TEV
DS1000 family
12VDC/1A,
switching,
"small" connector
(3.5mm)
APR-
P0008
APR-
P0009
APR-
P0010
DS1202, DS1206,
DS1026N,
EM1202EV
12VDC/0.5A,
switching,
"small" connector
(3.5mm)
APR-
P0011
APR-
P0012
APR-
P0013
