Tibbo EM1000 User Manual

155 Programmable Hardware Manual (PHM)
© Tibbo Technology Inc.
Ethernet interface
10/100BaseT Ethernet, Auto-MDIX
Wi-Fi interface
Optional, uses GA1000 add-on module
GPRS interface
Optional, uses TELIT GC864 GPRS module
(www.telit.com)
Serial ports
4 ports, CMOS-level.
UART capabilities
Baudrates up to 921'600bps;
none/even/odd/mark/space parity and 7/8
bits/character.
Max. load current for each
I/O line
10mA
Square wave generator
6Hz - 22'1184MHz, connected to buzzer
Real-time counter (RTC)
40 bit, increments at 128Hz
RTC backup power source
Supercapacitor, supports RTC for app. 6 days
Clock frequency
11.0592MHz with PLL off
88.4736MHz with PLL on
Flash memory
1024KBytes, entire memory minus 64KB is available
to store Tibbo BASIC/C application and data.
Typical write endurance is 100'000 write cycles per
256-byte sector. See the warning in Flash and
EEPROM Memory.
EEPROM memory
2048 bytes, 2020 bytes available to store
application data.
Typical write endurance is around 1'000'000 write
cycles per 16-byte EEPROM sector. See Prolonging
and Estimating EEPROM life.
Power supply voltage
10-18VDC
Operating temperature
-30 to +80 degrees C
Operating relative humidity
10-90%
Board dimensions
76x85mm
Pin diameter
0.64mm
All specifications are subject to change without notice and are for reference only.
Tibbo assumes no responsibility for any errors in this Manual, and does not make
any commitment to update the information contained herein.
Think the above table should contain additional data? Do not just assume that you
know the answer — talk to Tibbo! Remember that the ultimate responsibility for all
decisions you make regarding the use and the mode of use of Tibbo products lies
with you, our Customer.
IB100x Interface Boards
The following IB100x series interface boards are currently available:
· IB1000 (4 RS232 ports)
· IB1002 (4 RS232/422/485 ports)
· IB1003 (4 isolated RS232/422/485 ports)

Tibbo EM1000 Specifications

General

Brand	Tibbo
Model	EM1000
Category	Control Unit
Language	English
