4 synchronous serial ports with SPI and I2C modes.
·
Supports LCD and OLED panels*.
·
Supports matrix and binary output keypads*.
·
RTC with backup power input (optional onboard supercapacitor).
·
22KB SRAM for Tibbo BASIC/C variables and data.
·
1MB flash memory for TiOS, application code, and file system.
·
2048-byte EEPROM for data storage.
·
Three status LEDs onboard:
- Green and red main status LEDs;
- Yellow Ethernet link LED.
·
Two control lines for external green and red main status LEDs;
·
Software- and hardware-controlled PLL for selecting high or low speed.
·
Reliable power-on/ brown-out reset circuit.
·
Powering options:
- Through the switching regulator, 12VDC nominal (8 ~ 20V);
- Using regulated 3.3V power (the regulator is bypassed).
·
The regulator can provide up to 1.3A @ 3.3V to external devices.
·
Power: 100mA @ 3.3V (100BaseT mode, full speed).
·
Dimensions (LxWxH): 75 x 36 x 17.5mm**.
·
Operating temperature range: -40 ~ +70 C.
·
Firmware is upgradeable through the serial port or network.
·
Tibbo BASIC/C application can be uploaded and debugged through the Ethernet
LAN (no additional debugging hardware is required).
·
CE- and FCC-certified.
* Must be connected externally.
**Not including RJ45, power jack, WA2000.
Programming features
·
Platform objects:
beep — generates buzzer patterns.
button — monitors the MD (setup) line.
fd — manages the flash memory file system and direct sector access.
io — handles I/O lines, ports, and interrupts.
kp — works with matrix and binary keypads.
lcd — controls graphical display panels.
net — controls the Ethernet port.
pat — "plays" patterns on up to five LED pairs.
ppp — accesses the Internet over a serial modem (GPRS, etc.).
pppoe — accesses the Internet over an ADSL modem.
romfile — facilitates access to resource files (fixed data).
rtc — keeps track of date and time.
